Autotransformer LATR SUNTEK 1000VA range 0-30 - 11322

Description:    F-CRAM  motor Phase:         Single Voltage:       100V 110V 115V 120V 220V 230V Frequency:      50/60HZ Out Power:      10w Type of bearing:      Ball bearing Protection:      Thermal cutoffs or Automatic reset thermal protector Rotation:       CW. or CCW. Speed:         3400rpm   We are a blower motor manufacturer, our products including variable speed blower motor, axial flow machine motor, axial fan shaded pole motor, blower shaded pole motor, small blower shaded pole motor, drying fan shaded pole motor, etc. The goal is to achieve the corporation at ODM and OEM basis & to provide the components required for the manufacturing. The strategy of the company is to provide customer the products with good quality & reliable service.

Advantages ◈YB2 series motor is a high-efficiency whole three-phase asynchronous motor, suitable for fueling equipment.◈The power grade and installation size conform to IEC standards.◈It improves the explosion-proof and safety performance, promoting the reliability of motor effectively.◈This motor also reduces the nosie and vibration in operation.◈It enhances the economical efficiency and energy-saving effect of motor oeprating, and operational reliability of explosion-proof motor.◈The wide application of YB2 series motor not only has significant role in safety production among petroleum industry, but also shows obvious social economical benefit. Installation & Dimension YBJY80M2-4 installation dimension table (mm) A A/2 B C D E F G H K AB L HD AD 125 62.5 100 50 1916 40 65 15.513 80 10 165 310 165 105 Using Condition ◈Rated power: 0.12-3kw◈Rated voltage: 380V;◈Rated frequency: 50Hz;◈Insulation grade: F grade, the temperature rise is assessed by 80K;◈The ambient air temperature range is: -15℃~40℃;◈Altitude: no more than 1000m;◈Rated working system: S1 works continuously.

Buy dry cast resin transformers at an affordable price. These three-phase devices are designed to power converter equipment for various purposes. Basically, such transformers are used for: - excitation systems of hydro and turbo generators; — providing power to the electric drive of the drilling rig, as well as semiconductor converters of traction substations of urban electric transport (trams, trolleybuses, metro); — operation in rectifier units, in power electrical installations included in the traction power supply system of railways; — power supply of electric drives with direct and alternating current. Advantages: environmental safety, natural air cooling, resistance to low temperatures and precipitation, fire safety. Characteristics: - type of insulating winding: TLSP, TLSZP, TRLSP AND TRLSZP; — power: up to 3200 kVA; — voltage class: up to 10 kV; — execution and quality comply with GOST requirements; — country of origin: Russia. All products are tested in our own automated testing laboratory, which allows us to perform standard, acceptance and certification tests of products. The equipment is guaranteed for 3 years from the date of commissioning. 3-year warranty from the date of commissioning We deliver our equipment to any region and the CIS. To clarify prices for dry-type transformers and order power equipment with the required parameters, call our manager. All equipment is shipped with a full set of documents: - Passport - Test report - Operation manual - Sales and purchase agreement - We will produce shipping documents in a short time. We control the quality of production at all stages.

IRIS is the world's first patented energy management equipment based on carbon nanotube technology that does not use Voltage Regulation to save energy. IRIS offers a new chemically based system that makes your current electrical system more efficient. Unlike other energy saving devices that drop voltage, IRIS does not consume any voltage or current so it will not cause any harmful effect on the installed system. IRIS uses parallel installation and is usually installed after the Circuit Breaker and dispersed installation for each circuit is also possible. Installation usually takes about 30 minutes per unit. Available model is from NF-10 (for 10 kVA) to NF-1000 (for 1,000 kVA). Over 1,000 kVA, more than two units of IRIS can be installed in parallel connection. In short, there is no other energy saving product that compares to IRIS on the market.

Three-phase automatically transformers (variac transformers) with a range of output voltage control from 0 to 430 Volts with an LCD display. Specifications:   Rated power, VA 30000     Maximum current, A 40     Operating input voltage range, V 0-380     Nom. output voltage range, V 0-430     Output voltage error,% less than 1%     Warranty 2 years     Distortion sine wave missing     Connection option terminals (connection kit)     Operating range t ° C -5 - +50     Cooling passive     Network Connection Method terminals     Housing metal     Overall dimensions h-v-cm 34х26,5х113,5     Weight, kg. 102

Three-phase automatically transformers (variac transformers) with a range of output voltage control from 0 to 430 Volts with an LCD display. Specifications:   Rated power, VA 20000     Maximum current, A 27     Operating input voltage range, V 0-380     Nom. output voltage range, V 0-430     Output voltage error,% less than 1%     Warranty 2 years     Distortion sine wave missing     Connection option terminals (connection kit)     Operating range t ° C -5 - +50     Cooling passive     Network Connection Method terminals     Housing metal     Overall dimensions h-v-cm 32х26,5х59     Weight, kg. 60

Three-phase automatically transformers (variac transformers) with a range of output voltage control from 0 to 430 Volts with an LCD display. Specifications:   Rated power, VA 15000     Maximum current, A 20     Operating input voltage range, V 0-380     Nom. output voltage range, V 0-430     Output voltage error,% less than 1%     Warranty 2 years     Distortion sine wave missing     Connection option terminals (connection kit)     Operating range t ° C -5 - +50     Cooling passive     Network Connection Method terminals     Housing metal     Overall dimensions h-v-cm 32х26,5х59     Weight, kg. 50

Three-phase automatically transformers (variac transformers) with a range of output voltage control from 0 to 430 Volts with an LCD display Specifications:   Rated power, VA 9000     Maximum current, A 12     Operating input voltage range, V 0-380     Nom. output voltage range, V 0-430     Output voltage error,% less than 1%     Warranty 2 years     Distortion sine wave missing     Connection option terminals (connection kit)     Operating range t ° C -5 - +50     Cooling passive     Network Connection Method terminals     Housing metal     Overall dimensions h-v-cm 29х23х52     Weight, kg. 33 Application areas: - in all cases where non-standard voltage is required; - used in industries where temperature control is required; - as an additional device for transistor recorders, machine tools; - in scientific laboratories; - on the productions involved in the design and adjustment of TV receivers and other household appliances; - when testing fuses, regulation of relays, circuit breakers, current limiters, etc.; - in the oil and other industries.

Three-phase automatically transformers (variac transformers) with a range of output voltage control from 0 to 430 Volts with an LCD display. Specifications:   Rated power, VA 6000     Maximum current, A 8     Operating input voltage range, V 0-380     Nom. output voltage range, V 0-430     Output voltage error,% less than 1%     Warranty 2 years     Distortion sine wave missing     Connection option terminals (connection kit)     Operating range t ° C -5 - +50     Cooling passive     Network Connection Method terminals     Housing metal     Overall dimensions h-v-cm 26х20,5х50     Weight, kg. 26

Three-phase automatically transformers (variac transformers) with a range of output voltage control from 0 to 430 Volts with an LCD display. Specifications:   Rated power, VA 3000     Maximum current, A 4     Operating input voltage range, V 0-380     Nom. output voltage range, V 0-430     Output voltage error,% less than 1%     Warranty 2 years     Distortion sine wave missing     Connection option terminals (connection kit)     Operating range t ° C -5 - +50     Cooling passive     Network Connection Method terminals     Housing metal     Overall dimensions h-v-cm 18х25х37     Weight, kg. 22   Three-phase Variac transformer SUNTEK is a powerful and reliable device that is indispensable in production, in workshops and factories. Meter scale and digital voltmeter contribute to the simplicity and ease of operation. The metal case protects the autotransformer from mechanical damage. The main difference between laboratory autotransformers and conventional ones is that the mobile contact in the winding allows changing the number of turns included in the circuit and thus makes it possible to set the voltage in a wide range, for example, in a single-phase network – from 0 to 300 V, in a three-phase – from 0 to 430 V. the change in The number of turns occurs smoothly, so it is possible to obtain the most accurate voltage values and a pure sine wave at the output. In addition, this device is lighter and more compact than analogues made according to the traditional scheme, and has a much greater efficiency (up to 98%). To control the operation of the control panel has a voltmeter and ventilation grilles in the body contribute to the natural cooling of the device and prevent overheating.

The variac transformer SUNTEK RED 5000VA is a single-phase device with an LCD board that operates on 220 V mains and is used to permanently hold a given output voltage. Operating range variac transformers 0-300 volts. Rated current 20 A. Specifications:   Rated power, VA 5000     Maximum current, A 20     Operating input voltage range, V 0-250     Nom. output voltage range, V 0-300     Output voltage error,% less than 1%     Warranty 2 years     Distortion sine wave missing     Connection option terminals (connection kit)     Operating range t ° C -5 - +50     Cooling passive     Network Connection Method terminals     Housing metal     Overall dimensions h-v-cm 25х31х28     Weight, kg. 17   Variac transformer is a type of transformer. The two windings in this device are directly connected to each other. As a result, between them there are two types of communication, one of which is electromagnetic, and the other electric. The coil has several pins with different voltage output values. The difference from conventional transformer is increased efficiency, due to partial change in power. The autotransformer in our time has found wide application both for industrial purposes and in everyday life. Variac transformer (laboratory autotransformer with manual adjustment) - the need of any radio amateur, allows you to find out the technical characteristics of radio elements, chips, devices and homemade products. Find out the exact characteristics and behavior at different voltages, currents, temperatures will allow experiments and measurements carried out with the help of Variac transformers of low power (test relays, capacitors, microcircuit, working circuit, etc.). Variac transformer SUNTEK with adjustable output voltage from 0 Volt to 300 Volt with LCD display, displaying the output voltage as accurately as the switch variac transformer, is indispensable in these cases.

The variac transformer SUNTEK RED 2000VA is a single-phase device with an LCD board that operates on 220 V mains and is used to permanently hold a given output voltage. Operating range variac transformers 0-300 volts. Rated current 8 A. Specifications:   Rated power, VA 2000     Maximum current, A 8     Operating input voltage range, V 0-250     Nom. output voltage range, V 0-300     Output voltage error,% less than 1%     Warranty 2 years     Distortion sine wave missing     Connection option plug/socket     Operating range t ° C -5 - +50     Cooling passive     Network Connection Method plug/socket     Housing metal     Overall dimensions h-v-cm 19х20х18     Weight, kg. 8   Variac transformer is a type of transformer. The two windings in this device are directly connected to each other. As a result, between them there are two types of communication, one of which is electromagnetic, and the other electric. The coil has several pins with different voltage output values. The difference from conventional transformer is increased efficiency, due to partial change in power. The autotransformer in our time has found wide application both for industrial purposes and in everyday life. Variac transformer (laboratory autotransformer with manual adjustment) - the need of any radio amateur, allows you to find out the technical characteristics of radio elements, chips, devices and homemade products. Find out the exact characteristics and behavior at different voltages, currents, temperatures will allow experiments and measurements carried out with the help of Variac transformers of low power (test relays, capacitors, microcircuit, working circuit, etc.). Variac transformer SUNTEK with adjustable output voltage from 0 Volt to 300 Volt with LCD display, displaying the output voltage as accurately as the switch variac transformer, is indispensable in these cases.
