Boiler KVm 1.6 with TSPM The design of the boiler KVm 1.6 with TSPM (KVm 1.86) includes: high efficiency fuel combustion efficiency economic efficiency compactness reliability ease of use increased maintainability ease of installation lack of scale The KVm 1.6 hot water boiler with TShPM-2.0 is characterized by high efficiency, which is achieved through the use of the following design solutions. The large volume of the combustion chamber ensures complete combustion of fuel, thereby reducing losses with mechanical underburning. Gas-tight design of the furnace and high-quality thermal insulation reduce heat losses through the walls of the boiler and the environment and exclude the suction of cold air into the boiler furnace. The developed convective heating surface ensures a decrease in the temperature of flue gases from the boiler to 180-200 ° C. The use of modern technology of fuel combustion in a bed reduces losses with mechanical and chemical underburning of fuel. The hydraulic circuit in the boiler works according to the counterflow circuit and the convective package acts as an economizer. Numerous partitions installed in the boiler collectors direct the flow of the coolant, eliminating the occurrence of stagnant zones and local overheating of heating surfaces, high speeds and turbulization of the water flow minimize the formation of scale, KVm 1.6 boilers operate reliably without special measures for chemical water treatment. Technical characteristics of a hot water boiler KVm 1.6 Gcal with TShPM-2.0 Power of a hot water boiler, Gcal / h (MW) 1.6 (1.86) Heated area with a ceiling height of 3 m, m² 12500 Fuel, coal Kuznetskiy D Kharanorskiy B1 Net calorific value 5230 2720 Boiler efficiency, not less,% 83 77 Fuel consumption, kg / h 370 764 Equivalent fuel consumption, kg / h 276 Outgoing temperature their gases, ° C Not more than 550 Working medium consumption, m³ / h 64 Water temperature, ° C 70-95 < td> Working medium pressure, MPa (kgf / cm²) 3-6 Boiler hydraulic resistance at a temperature difference of 25 ° C , MPa (kgf / cm²), no more than 0.07 (0.7) Aerodynamic resistance, Pa (mm water column), Combustion mirror area, m2 no more than 550 Combustion device KVr RPK furnace Gabaoite dimensions of the boiler block, no more < tr> Length, mm 4500 Width, mm 1950 Height, mm 3100
