Shanghai FillPack With 10+ years of experience in the non-standard development of various types of filling and packaging equipment, we have reserved a variety of mature solutions in different application fields such as daily chemicals, food, pharmaceuticals, beverages, etc., to protect your product quality in all directions. Shanghai FillPack With a group of engineering R&D designers and experienced production technicians who have worked in the field of automation equipment manufacturing for many years and cooperated with German companies, the work combination is full of vigor, innovation, and dedication, and is a competitive and cohesive force. Combine all our wisdom and technology and relentlessly pursue the realization of various ‘may’. Shanghai FillPack Adhering to the entrepreneurial philosophy of "Quality changes everything, service achieves the future", along the development path of "quality, integrity, professionalism, innovation, judgment, action", challenge the limits!
Make a safe deal with this supplier.
Apply
Spout pouch filling capping machine for juice, yogurt, water, jelly, soy milk, peanut butter - 90447
Shanghai FillPack Intelligent Technology Co.,Ltd
Shanghai, China
Specify the price
Introduction and application:
The spout pouch filling packing machine consists of pouch supply, filling, cap supply, cap sorting, and capping parts, fully automatic! Which is applied for filling different kinds of liquid and viscous liquid. Such as juice yogurt, water, jelly, soy milk, cooking oil, liquid soap, tomato sauce, jam, chocolate spread, etc.
Feature:
1. Model FP-ZLD series is a spouted pouch-filling capping machine.
2. It is widely applied in different products such as juice yogurt, water, jelly, soy milk, cooking oil, liquid soap, etc. Also used for semi-fluid, for example, tomato sauce, jam, chocolate spread, etc.
3. Fully automatic pouch supply, filling, cap supply, cap sorting, and capping.
4. It with 4 filling nozzles max packing speed of 2000-6000 pouches/hour.
5. International spare parts brand that ensures stable performance.
6. Easy to operate by touch-sensitive screen, PLC, and electric control system
7. High quality and performance, the frame is made of 150mm thickness 304# stainless steel.
8. Special designed non-drip filling nozzle to prevent dripping.
9. No bag – no filling- no sealing.
Specification:
MODEL
FP-ZLD
Equipment Structure
Filling capping combi
Equipment Material
304 stainless steel
Measurement Way
Piston measurement
Operation Interface
Touch screen
Applicable product
Liquid and Viscous products
Packaging bag material
Complex film
Packaging bag size
Width: 180mm-300mm
Working process
Step 1: Supplying premade bags
Step 2: Filling
Step 3. cap loading
Step 4: cap screwing
Product weight
10-500ml customizable
Measure hopper capacity
≥20KG
Packaging speed
2000-6000 pcs/hr.
Equipment weight
650KG
Equipment Size
2420×1520×1560mm (L*W*H)
Working Power
1.5KW
Air Consumption
0.8 m³/min
Shanghai FillPack Intelligent Technology Co.,Ltd
Shanghai, China
Specify the price
This Jar filling capping line is consist of a thick paste-filling machine and a vacuum capping machine which is specially used for sauces, jam, and paste products. such as chocolate spread, chili paste, peanut butter, honey, butter, mayonnaise, and ketchup...
Technical parameter:
Item: Piston pump filling machine
Filling nozzle: 2-16 (customized based on production capacity)
Filling system: Piston pump
Filling range: 100-1000ml
Filling speed: 500-6,000 jars /hour
Filling precision: ±1%
Power: 380V 50/60Hz, 2Kw
Air pressure range: 0.6-0.8Mpa
Weight: To be confirmed
Machine size: To be confirmed
Shanghai FillPack Intelligent Technology Co.,Ltd
Shanghai, China
Specify the price
General description
This liquid filling machine is consist of bottle rinsing, filling, and capping functions for all types of hot-filling products like concentrated juice, pulp juice, fresh juice, etc.
Rinser
The bottle enters the rinsing part of the three-in-one machine through the air conveyor. The gripper installed on the rotary disk catches the bottle and turns it over 180 degrees and makes the bottleneck face ground. In the special rinsing area, the nozzle on the gripper sprays juice to rinse the bottle inwall. After rinsing and draining, the bottle turns over 180 degrees along the guide rail and makes the bottleneck faces the sky. Then rinsed bottle is transferred to the filling part by poking the bottle starwheel. The bottle that enters into the filler is held by a neck-holding plate. The filling valve acted by the cam can realize up and down. It adopts a pressure-filling way. The filling valve opens and begins filling when it moves down and touches the bottleneck, the filling valve moves up and leaves the bottleneck when it finishes filling, and the full bottle is transferred to the capping part through the hold neck transition poking wheel. The stop-screwing knife holds the bottleneck and keeps the bottle upright not rotating. The screw capping head keeps in revolution and autorotation. It can finish a whole capping course including catching, pressing, screwing, and discharging through the action of the cam. The full bottle is transferred to the bottle outlet conveyor to the next process through the starwheel. The whole machine is enclosed with windows, the height of the enclosed window is higher than the peak of the 3-in-1 machine, in the bottom of the enclosed window has a return air outlet.
Filler
This part is mainly used for filling juice after finishing the bottle rinse.
The filling machine is introduced by German technology and uses the normal pressure fill principle to design and produce.
It adopts a normal pressure mechanism valve, making the filling with high speed and high precision of liquid level. Double leading bars elevator structure to make the bottle up and stable.
The main drive transmission adopts a gear transmission that is an opening combination drive, with high efficiency, low noise, long life, easy maintenance, full lubrication, and use of transducer control the main drive motor speed, this machine is non-degree conversion frequency speed control.
Bottle guiding system, the structure is simple, it can quickly and easily change according to different bottle volumes, this whole machine is transported by the clipping bottleneck method.
PLC is controlled by itself, fault display online, e.g. bottle block or non-cap, etc.
In the filling tank, the product material control itself, and the liquid level height adopts a liquid level sensor to test and make sure a stable liquid level and reliable filling.
This machine's main spare parts and electrical components are import products.
Capper
The capping part finishes the work to cap the bottles after filling by cap elevator, and the cap is conveyed to the following procedure by the conveyor chain.
The capping machine rotates through a reduction box drive rotational wheel, to make the cap leave the hopper with the function of centrifugal force. There is a separation device for the right cap and the wrong cap at the exit, when the wrong cap passes, the cap automatically falls into and returns to the pipeline, and blows the wrong cap automatically to the hopper through wind power. Only the right cap could enter into skids smoothly, the volume of the cap inside of the hopper will be automatically inspected by the electric switch to control the cap conveyor, and that ensures the best effect of the cap down. When the right cap enters into the slideway, it could smoothly enter into the cap feed plate, to prevent accidents, there is an anti-wrong cap drive plate device to match with the slideway, to ensure that the access to the cap feed plate is correct. The slideway is also equipped with a pair of photoelectric switches when testing no cap, then an immediate halt to the host. In order to effectively remove non-anti-theft ring bad caps and clean up additional caps in the hopper, there is an active exit in front of the hopper exit that can meet this function.
Technical parameter:
Model: FP-CGGF
Washing head: 8,12,14,16,18,24,32...
Filling head: 8,12,14,16,18,24,32...
Capping head: 4,6,8,10,12...
Production capacity: 3000-24000b/hr.
Air source pressure: 0.6-0.8MPa
Air consumption: 3M3/H
Rinsing juice pressure: 0.15-0.2 MPa
Bottle height: 150-340MM
Bottle diameter: Φ50-Φ120MM
Rinsing water consumption: To be confirmed
Filling way: Hot filling
Power: 3ph, 380V/50Hz,4.5KW
Overall size: 4500*2000*2400 (L*W*H) mm
Weight: 2500Kg
